40W 808nm Diode Laser nrog 15m Fiber
Lub hauv paus ntsiab lus ua haujlwm ntawm 40W 808nm Fiber Coupled Diode Laser feem ntau suav nrog laser tiam, fiber ntau kis tau tus mob, coupling mechanism, thiab beam zoo tswj. Lub laser diode yog ib qho khoom siv nrog cov khoom siv semiconductor uas ua tiav lub teeb amplification nyob rau hauv qhov tsim nyog sab nrauv (xws li kev txhaj tshuaj tam sim no), thiab thaum kawg tso tawm siab -brightness, siab -coherence laser teeb. Raws li qhov nruab nrab rau kev sib kis ntawm laser, fiber ntau optical muaj qhov zoo xws li kev poob qis, kev xa tawm siab, thiab tsis kam mus rau electromagnetic cuam tshuam. Lub lens tuaj yeem ua kom pom tseeb ntawm lub teeb ntawm lub laser diode mus rau cov tub ntxhais ntawm cov khoom siv kho qhov muag, yog li ua tiav kev sib kis tau zoo ntawm cov teeb liab kho qhov muag.
Cov ntsiab lus ceev:
Quality warranty yog ib xyoos. Lub neej ntev tshaj 10000hours.
Fiber ntev tuaj yeem hloov kho.
Brandnew tuaj yeem hloov kho rau cov neeg siv khoom raws li lawv cov kev xav tau tshwj xeeb
ESD tiv thaiv - Electrostatic paug yog thawj qhov ua rau cov khoom lag luam poob siab. Ua kom ceev faj heev los tiv thaiv ESD. Siv lub dab teg pluaj, qhov chaw ua haujlwm hauv av thiab cov txheej txheem antistatic nruj thaum tuav cov khoom.
Specification:
Yam khoom: FC808DL40
| Kho qhov muag | |
| Center Wavelength | 808nm ua |
| Wavelength kam rau ua | ± 5nm |
| Tso zis zog | 40W |
| Spectral Width FWM | 4nm ua |
| >95% zog | 0.18 NOS |
| Slope Efficiency | 4W/A |
| Fiber ntau | |
| Fiber Khoov Radius | 75mm ua |
| Fiber Connector | SMA905 |
| Hluav taws xob | |
| Kev khiav hauj lwm tam sim no Iop | 12A |
| Threshold Current Ith | 1.0A |
| Ua haujlwm Voltage Vop | 9.0V |
| Kub | |
| Ua haujlwm kub | 15-55 ° C |
| Cia Kub | -30-70 degree |
Loj:
![F]H((D_DQ6%3030%_NWG{VU](/Content/uploads/202098745/202003131328147269466.png "product-1-1")
Cim npe nrov: 40W 808nm Fiber Coupled Diode Laser lwm tus neeg, manufacturers Tuam Tshoj, hoobkas, lag luam wholesale, ua nyob rau hauv Suav teb
