9W 976nm VBG Fiber Laser Diode
Nta:
Ib leeg emitter-raws li laser diode module nrog ntim Bragg grating (VBG)
Wavelength stabilized tshaj temp thiab tam sim no
9W tso zis zog
High plug efficiency
0.22NA, 105um fiber ntau tub ntxhais txoj kab uas hla
Nqaim bandwidth
Daim ntawv thov:
Dav siv nyob rau hauv fiber ntau laser twj, cim, txiav, engraving, illumination thiab scientific kev tshawb fawb
Daim ntawv qhia:
Yam khoom no: FC976WS9
| Kho qhov muag | |
| Center Wavelength | 976nm ua |
| Wavelength kam rau ua | ± 0.5nm |
| Tso zis zog | 9W |
| Hluav taws xob | |
| Kev khiav hauj lwm tam sim no Iop | 12A |
| Threshold Current Ith | 0.7A |
| Ua haujlwm Voltage Vop | 1.8V |
| Kub | |
| Ua haujlwm kub | 15-55 ° C |
| Cia Kub | -30 ~ 70 degree |
| Wavelength Temperature Coefficient | 0.01nm / degree |
Daim duab:
FAQ:
Koj puas tuaj yeem ua OEM (tsim thiab tsim cov lasers rau cov neeg siv khoom)?
Yog lawm, peb muaj cov kws tshaj lij R & D pab pawg suav nrog software, kho vajtse, hluav taws xob thiab cov kws tsim qauv 3D thiab muaj peev xwm txaus los tsim cov lasers tag nrho raws li cov neeg siv khoom xav tau.
Koj puas muab kev lees paub rau cov khoom?
Yog, tag nrho cov khoom tau raug kuaj ua ntej xa tawm.
Kev pab txhawb nqa lub neej ntev . 2 xyoo warranty.
