Hangzhou Brandnew Technology Co., Ltd. yog ib lub tuam txhab ua lag luam hauv Suav teb thiab cov khoom lag luam zoo tshaj plaws 700mw 850nm laser nti tuag ib hom rau biomedicine. Kev khiav hauj lwm hauv xeev- ntawm- lub- lub Hoobkas kos duab, peb tshwj xeeb hauv tag nrho cov khoom tsim tawm - los ntawm siab- cov chips kev ua tau zoo, TO/F/C Mounts, COS, thiab MCC tuav, kom muaj zog pawg thiab qib siab fiber ntau-coupled solutions.
700mW 850nm Laser Chip Tuag Tib Hom rau Biomedicine
Nta:
- 850nm nyob ze -infrared band, mus txog 700mW ib qho - hom tso zis
- Bare laser chip tuag, hloov tau rau cov neeg siv khoom sib dhos
- Tib - hom haum rau lub tsev sab nraud kab noj hniav tunable laser
Daim ntawv thov:
- Kev loj hlob ntawm sab nraud kab noj hniav tunable laser kev koom ua ke nrog ib leeg -mode waveguide
- Biomedical optical imaging, fluorescence excitation thiab spectroscopic kev tshawb fawb
- Optical coherence tomography (OCT) system qauv tsim
- Laboratory spectral test, nonlinear optics thiab optoelectronic sim platforms
Qhov no 700mW 850nm ib leeg-mode laser liab qab tuag muab kev ua tau zoo tib yam - hom kev ua tau zoo rau kev ntim khoom thiab kev tsim kho qhov muag. Nws yog tshwj xeeb muaj feem xyuam rau kev tsim kho sab nraud kab noj hniav tunable lasers txuam nrog ib zaug xwb -mode waveguides, thiab dav siv nyob rau hauv biomedical imaging, spectral tsom xam thiab lwm yam kev tshawb fawb tej yaam num.
Daim ntawv qhia
Yam khoom: LC850SE07
| Kho qhov muag | Min | Ntaus | Max | Chav tsev |
| Center Wavelength | 846 | 849 | 853 | nm |
| Tso zis zog | 700 | mW | ||
| Ua hauj lwm hom | CW | |||
| Fais fab Modulation | 100 | % | ||
| Emitter Dav | 3 | ua um | ||
| Chip Dav | 500 | ua um | ||
| Cavity Length | 3995 | 4000 | 4005 | ua um |
| Chip Thickness | 110 | 130 | 150 | ua um |
| Fast Axis Divergence (FWHM) | 15 | 17 | 19 | Deg |
| Slow Axis Divergence (FWHM) | 3 | 5 | 7 | Deg |
| Spectral Bandwidth (FWM) | 2 | 3 | nm | |
| Pulse Wavelength | 844 | 847 | 850 | |
| Polarization hom | TE | |||
| Slope Efficiency | 0.09 | 1.02 | 1.04 | W/A |
| Hluav taws xob | ||||
| Kev khiav hauj lwm tam sim no Iop | 0.9 | 1.0 | A | |
| Threshold Current Ith | 0.1 | 0.13 | A | |
| Ua haujlwm Voltage Vop | 1.85 | 1.95 | V | |
| Kub | ||||
| Kev ntsuas kub | 25 | degree | ||
| Wavelength Temperature Coefficient | 0.28 | nm / degree |
