45W 976nm Wave Locked Laser Diode
45W 976nm Wave Locked Laser Diode yog cov khoom siv uas lub teeb tsim tau ua ke rau hauv fiber ntau optical. Coupling cov zis ntawm lub laser diode rau hauv ib qho optical fiber ua rau xa lub teeb yooj yim dua. Qhov no tso cai rau lub teeb laser kis tau mus ntev yam tsis tau poob lub zog ntau dhau.
Cov ntsiab lus ceev:
976nm xauv wavelength, ± 0.5nm wavelength kam rau ua
45W tso zis fais fab, lwm lub zog kuj muaj
Customized muab kev pabcuam
Daim ntawv thov:
Pumped Laser
Pumped khoom-lub xeev laser
Kev ua cov khoom siv
Daim ntawv qhia
Yam khoom no: FC976WS45
| Kho qhov muag | |
| Center Wavelength | 976nm ua |
| Wavelength kam rau ua | ± 0.5nm |
| Tso zis zog | 45W |
| Fiber ntau | |
| Fiber tub ntxhais | 105 ua |
| Fiber NA | 0.22 NOS |
| Fiber Length | 1m |
| Fiber Connector | SMA905 |
| Hluav taws xob | |
| Kev khiav hauj lwm tam sim no Iop | 12A |
| Threshold Current Ith | 0.7A |
| Ua haujlwm Voltage Vop | 9V |
| Kub | |
| Ua haujlwm kub | 15-55 ° C |
| Cia Kub | -30 ~ 70 degree |
| Wavelength Temperature Coefficient | 0.01nm / degree |
Daim duab:
FAQ:
Yuav ua li cas mus ua ib qho kev txiav txim?
1. Tiv tauj peb kom paub meej ntxiv los ntawm email
2. Peb xa PI rau koj rau kev them nyiaj, lub sijhawm them nyiaj yog T / T lossis Western Union
3. Thaum them nyiaj tiav, peb yuav npaj ntau lawm
4. Lub sij hawm xa tuaj yog 1-2 lub lis piam nyob ntawm qhov kev txiav txim sib txawv qty thiab thov.
5. Tom qab xa khoom, peb yuav xa koj DHL UPS FedEx TNT taug qab tsis muaj.
