500w 976nm Kab rov tav Diode Laser Array
G-Stack Diode Lasers Conduction-txias QCW arrays rau kev siv, teeb pom kev zoo, thiab kev xav tau ncaj qha diode.
Conductive cooled high-power diode laser pawg yog kab rov tav txheej txheem ntawm cov tuav. Qhov no diode laser pawg muaj qhov muag pom lub zog ntawm 500W QCW. Lub diode laser pawg yog muaj nrog 5 tuav nyob rau hauv kab raws li tus qauv thiab nrog yoj qhia.
Daim ntawv thov:
Pumping ntawm solid-state lasers
Kev ua cov khoom siv
Optical: | |
Center Wavelength λ | 976nm ua |
Wavelength kam rau ua | ± 5nm |
Tso zis zog | 100W |
Tus naj npawb ntawm Bar | 5 |
Ua hauj lwm hom | QCW |
Pulse Dav | ≤ 230 peb |
Lub luag haujlwm Cycle | ≤2% |
Ntau zaus | ≤ 240Hz |
Spectral Width FWM | ≤ 7nm |
Fast Axis Divergence (FWHM) | ≤41 Deg |
Slow Axis Divergence (FWHM) | ≤11 Deg |
Polarization hom | TE |
Slope Efficiency | ≥1.0W/A |
Hluav taws xob: | |
Kev khiav hauj lwm tam sim no Iop | ≤102A |
Threshold Current Ith | ≤13A |
Ua haujlwm Voltage Vop | ≤10V |
Fais fab Hloov Efficiency | ≥56% |
Thermal: | |
Ua haujlwm kub | 70℃ |
Cia Kub | -40-85℃ |
Wavelength Temperature Coefficient | 0.33nm / ℃ |
Cov ntawv pov thawj
